Interactive Shell

RAPS includes a powerful interactive shell with advanced features like TAB completion, parameter hints, and command history.

Starting the Shell

raps shell

You’ll see a welcome message with usage tips:

Welcome to the RAPS interactive shell!
Type 'help' for a list of commands, 'exit' to quit.
Use TAB for command completion, hints show required parameters.

raps>

⭐ Key Features

🔥 TAB Completion

Press TAB to auto-complete commands, subcommands, and flags:

raps> bu[TAB]
bucket               Bucket operations (OSS)

raps> bucket cr[TAB]
create               Create a new bucket

raps> bucket create --[TAB]
--retention <transient|temporary|persistent>   --force

Smart completion includes:

  • Commands: auth, bucket, object, translate, etc.
  • Subcommands: Context-aware based on the current command
  • Flags: Shows available options with descriptions
  • Parameter types: Displays expected value formats

💡 Parameter Hints

Gray text hints show required parameters as you type:

raps> bucket create <BUCKET_KEY>
                    ↑ gray hint

raps> bucket create my-bucket [--retention <transient|temporary|persistent>]
                              ↑ optional flags shown

raps> object upload <BUCKET_KEY> <FILE_PATH>
                    ↑ shows multiple required parameters

raps> translate start <URN> [--format <svf|svf2>]
                      ↑ required  ↑ optional

Hint behavior:

  • Required parameters: Shown in <angle_brackets>
  • Optional flags: Shown in [square_brackets]
  • Multiple options: Shown as <option1|option2|option3>
  • Dynamic updates: Hints change as you add parameters

📝 Command History

Navigate through previous commands:

  • ↑ Arrow: Previous command
  • ↓ Arrow: Next command
  • Ctrl+R: Search command history
  • Auto-save: History persists between sessions

🎨 Enhanced Experience

# Colored prompt
raps> auth status

# Built-in help command
raps> help
Available commands:
  auth             Authentication (login, logout, status, test, whoami)
  bucket           Bucket operations (list, create, get, delete)
  object           Object operations (list, upload, download, delete)
  translate        Model Derivative (start, status, manifest, metadata)
  ...

Tips:
  • Press TAB for command completion
  • Gray text hints show required parameters
  • Use <command> --help or <command> -h for command help

🔧 Usage Examples

Interactive Authentication Flow

raps> auth status
❌ Not authenticated

raps> auth login --3lo
🔐 Opening browser for 3-legged OAuth authentication...
✓ Authentication successful!

raps> auth whoami
User: john.doe@company.com

Bucket and Object Operations

# Create a bucket with hints
raps> bucket create <BUCKET_KEY>
raps> bucket create my-project-files

# Upload with tab completion
raps> object upload my-project-files ./model.rvt
Uploading model.rvt...
████████████████████████████████████████ 100%
✓ Upload complete!

# Get URN for translation
raps> object urn my-project-files model.rvt
URN: dXJuOmFkc2sub2JqZWN0czpvcy5vYmplY3Q6...

Model Translation Workflow

# Start translation with format hints
raps> translate start <URN>
raps> translate start dXJuOmFkc2sub2JqZWN0czpvcy5vYmplY3Q6... --format svf2

# Check status
raps> translate status dXJuOmFkc2sub2JqZWN0czpvcy5vYmplY3Q6...
Status: success
Progress: 100%

⌨️ Keyboard Shortcuts

KeyAction
TABAuto-complete commands/parameters
↑/↓Navigate command history
Ctrl+CInterrupt current operation
Ctrl+DExit shell
Ctrl+LClear screen
Ctrl+RSearch command history

🔄 Shell Commands

Special commands available in interactive mode:

# Show command overview
raps> help

# Regular RAPS commands work normally
raps> bucket list
raps> auth test
raps> object upload my-bucket file.dwg

# Exit the shell
raps> exit
# or
raps> quit

💡 Pro Tips

1. Use Hints for Learning

The parameter hints are perfect for discovering command syntax:

raps> webhook create <SYSTEM> <EVENT> <CALLBACK_URL>
# Shows you exactly what parameters are needed

2. Tab Through Options

Use TAB to explore available subcommands:

raps> auth [TAB]
login    logout   status   test     whoami   inspect-token

3. Combine with Command Help

Use shell completion to discover commands, then get detailed help:

raps> translate [TAB]  # See available subcommands
raps> translate start --help  # Get detailed help

4. Scripting Integration

Test commands interactively, then copy to scripts:

raps> bucket create my-bucket --retention persistent
# Works great, now add to your script:
# #!/bin/bash
# raps bucket create my-bucket --retention persistent

🚨 Troubleshooting

Tab Completion Not Working

If TAB completion doesn’t work:

  1. Check Terminal: Ensure your terminal supports readline
  2. Update RAPS: Make sure you’re using v3.8.0 or later
  3. Terminal Settings: Some terminals may interfere with TAB handling

Hints Not Displaying

Gray parameter hints should appear automatically. If not:

  1. Color Support: Ensure your terminal supports ANSI colors
  2. Shell Settings: Check if hints are being overridden by terminal settings

History Issues

Command history is saved to .raps_history in your current directory:

# Check history file
ls -la .raps_history

# Clear history if needed
rm .raps_history
